Autotransformer Instruments Single Phase Lfzd

• Overview
• Partial Product Parameter

Overview

Basic Info.

Model NO.	LMZJ-0.66
Phase	Single
Operation Condition	Indoor
Usage	Protection
Winding Form	Single Layer & Tightly Wound Type
Insulating Medium	Epoxy Resin
Installation	Busbar Type
Magnetic Circuit Structure	Single Stage Type
Voltage Transformation Principle	Electromagnetic Type
Certification	ISO9001
OEM	Accept
Warranty	12 Months
Frequency	50Hz or 60Hz
Power Factor	Cos=0.8 (Lagging)
Rated Secondary Current	5A or 1A
Altitude	≤1000m
Shape	Round
Rated Voltage	0.66kv
Transport Package	Wooden Case
Specification	CE, RoHS
Trademark	Comewill
Origin	China

Product Description

Partial Product Parameter

We support various customized transformers

Type	Rated Current Ratio	Busbar		Accuracy class and rated output(VA)		Number of turns through the core	Rated insulation level
		Cross - sectional area	Number of pieces	0.5	1
LMZ1-0.66	15/5	10X10	/	5	7.5	10	0.66/3
	20/5	/	/			10
	30/5	/	/			5
	40/5	/	/			5
	50/5	/	/			/
	75/5	/	/			3
	100/5	/	/			2
	150/5	30X10	1			2
	200/5	30X10	1			1
	300/5	30X10	1			1
	400/5	30X10	1			1
	500/5	30X10	1			1
	600/5	30X10	1			1
LMZJ-0.66	750/5	100X10	1 - 2	10	15	1

COMEWILL has three subsidiaries (Juyi, Parber, Lexin), and has built a full - chain system covering R&D, production, sales and service.
Our products cover a wide range of electrical components like cable plug - in connectors,current and voltage transformers,temperature and humidity controllers,electromagnetic locks and heaters.We're committed to offering customers high quality products and services.And keep advancing to better satisfy their needs.

IF YOU NEED FURTHER INFORMATION ABOUT THE TRANSFORMER,PLEASE CONTACT US! WE PRODUCE VARIOUS TYPES OF CT/VT. OEM ODM
