EI Lamination Silicon Steel Core Power Transformer

Basic Info.

Model NO.	AL-PT107
Core	Core-type Transformer
Cooling Method	Dry-type Transformer
Winding Type	Auto-transformer
Certification	ISO9001-2000, ISO9001, CE
Usage	Single-phase Transformer
Frequency Characteristics	Low Frequency
Shape of Core	EI
Brand	AL TRANSFO
Working Frequency	50Hz or 60Hz
Storage Temperature	-25c to +85 C
Output Voltage	0~36V
OEM	Acceptable
Winding Material	100% Copper
Working Moisture	30-90%
Input Voltage	0~250V
Quality	100% Tested
Temperature Rise	Less Than 20 C
Advantage	Best Price & Best Quality in China
Weight	1.21kg~1.68kg
Transport Package	Export Carton on Strong Pallet
Specification	4pcs/box
Trademark	AL
Origin	China
HS Code	85043190
Production Capacity	5000PCS/15days

Product Description

Product Description

AL provides both standard and custom designs with following features

1. 105/130/155/180 degree insulation systems are available.
2. Design to meet UL/CSA/TUV/VDE/CE and other appointed safety agency requirements.
3. Auto transformer and insulated transformer can be design according to requirements.
4. 100/110/115/120/208/220/230/240/277/380/415V/440V or specified primaries are optional.
5. Secondary voltage: 3.6V/6.3V12V/24V/36V/100V/110V/120V/200V/220V/240V/380V or customer specified.
6. Terminations and mounting means can be customized.

Key Specifications
Power Range: 10VA to 3000 VA
Size Range: EI-28 to EI-192
Phase: Single or 3Phase
Input/Output: Customized
Insulation: Primary to secondary 2.5kV, 1min, some parts up to 4kV, it desponds to the safety agency requirements.
Primary to safety ground 2.5kV, 1min
Secondary to safety ground 1.5kV, 1min

Our Advantages:
1. 27 years experience in transformer and inductor manufacturing;
2. Scientific management system, strong technical team, and strict quality control system;
3. RoHS,CE,TUV and UL certified;
4. OEM & ODM;
5. Competitive price,in time delivery and perfect after-service online.


Packaging & Shipping

Application

Switching power supplies, chargers, alarm system, TV/CRT monitor displays, UPS, VCD/DVD players, audio/visual equipment, OA machines and inverter Typical products .

Used in high-density installation with good shielding quality also used in wave carrier filter, power transformer and Aux-power transformer .


Other products

FAQ

1. Question: Lead time for samples?

Reply: 3-5 working days.

2. Question: Lead time for mass production?

Reply: 7 to 15 working days or depending on order quantity.

3. Question: What should provide to make custom transformer ?

Reply: Supply drawing is best, or tells us the size, inductance, resistance and etc.

4 . Question : What is payment term ?

Reply : T/T , Western Union , PayPal or negotiation.
