Compact Mini AC Split

• Overview
• Principle
• Specification
• Applications
• Company Profile
• Packaging & Shipping
• FAQ

Overview

Basic Info.

Model NO.	CMCT-KH-10C
Phase	Single
Operation Condition	Indoor
Usage	Measurement
Insulating Medium	Epoxy Resin
Installation	Screw Mounting
Environmental Temperature	-20 ºC~70 ºC
Relative Humidity	≤ 85%
Rated Input Current	5A
Measuring Current Ranges	0.25~60A
Specification	standard
Trademark	Cheemi
Origin	China
HS Code	85043110
Production Capacity	10000PCS/Month

Product Description

Applicable conditions:
* Environmental temperature: -20 ºC~70 ºC, relative humidity ≤ 85%;
* Sea level: not exceeding 1000m;
* Atmospheric conditions: There are no gases, vapors, chemical deposits, dust, or other corrosive or explosive media that seriously affect the insulation of the transformer.

Technical requirements:
Comply with GB 1208-2006 "Current Transformers" standard and JB/T 10665-2066 "Micro Current Transformers" standard.

Stuctural requirements:
The appearance is atmospheric and beautiful, the structure is novel and unique, the volume is small and the weight is light, the
insulation and isolation ability is strong, and it is moisture-proof, anti-corrosion, and shockproof.
Our products are suitable for different industrial applications.

Q1:Can I get sample from you?
A:Yes,we can provide the free samples for your testing,please contact us for free and tell us which product you need.
Q2:Do you accept customization?
A:Yes,customization is acceptable,please contact our sales staffs for consult.
Q3:Can you provide help for technical issues?
A:Yes,we have more than 10 years of research and development in the electronic industry. If you need technical help in the purchase process, please feel free to contact us.
Q4 : Can I get a lower price if I order large quantities?
A : Yes,it's negotiable.
Q5: How about the quality guarantee period ?
A : Our warranty period is one year since from shipping date.
Q6: Can I add or delete items from my order if I change mind?
A : Yes, but you need to tell us asap, if your order has been done in our production line, we cannot change it.

Principle

This specification is widely used in charging stations, microcomputer protection, distribution and monitoring, electricity meters, power quality analysis, and electrical equipment signal acquisition power devices. It can also be used in digital instruments such as power transmitters, telemetry and remote control data acquisition systems, relay protection, etc. * Small size * High accuracy * Good consistency * Used for current and power measurement

Specification

Physical dimension:

Electrical parameters(Ta=25ºC±5):
Parameter	Symbol	Range	Unit
Rated input current	IPN	5	A
Measuring current ranges	IP	0.25~60	A
Secondary load	Rf	1:2000T RL≤10	Ω
Accurate	XPN	Rf=10Ω/IPN→5%~1200%@≤±0.5	%
Phase difference	δPN	Rf=10Ω/IPN→5%~1200%@≤90	min
voltage withstandK	VD	50Hz@rms/1min/>2.5	KV
Operating Frequency	f	50/60	HZ
Insulation Resistance	VDR	DC500V/1min/>500	MΩ

Test error(Ta=25ºC±5):

Current error ±%	Phase error ±′
Rated current	Rated current

0.25A	2.5A	5A	Imax	0.25A	2.5A	5A	Imax
≤±0.75	≤±0.5	≤±0.5	≤±0.5	≤±90	≤±80	≤±70	≤±70

Mechanical parameters:

Shell material	PA6	Shell color	Black
An input mode	Cable through core input	Magnetic core	Ferrite
Two output mode	2468#24AWG Red black, green black, yellow black, three color two core parallel lead out, with a length of 2 meters and cold pressed terminals	Enameled wire	QA-0.10mm - 155
Medium filling material	/	Weight	≤80g

Applications

Company Profile

Packaging & Shipping

Package
All our sensors will be well packed with bubble & carton. (Bubble packing→4 small carton→1 big carton)
You can choose your own label(Screen Print or Laser Engraving).
Can be netural packing or OEM.

Shipping
Products are shipped via UPS / DHL/ FedEx / TNT, etc. (door to door), or air & sea shipment for larger qty. L/T: 3-7 days upon receiving payment if the qty is lower than 1000PCS and it is not customized products. Shipping via DHL. UPS. FedEx and TNT express usually takes 3~7days dependent on the destination country.
