1500: 1 5mm Hole Mini PCB Mounting Current Transformer

ZMCT206-1500A Current Transformer Small size,high accuracy,good consistency,for current and power measurement Structural

Send inquiry

Basic Info.

Model NO.	ZMCT206-1500A
Phase	Single
Operation Condition	Indoor
Usage	Protection, Measurement
Winding Form	Multilayer Honeycomb Type
Insulating Medium	Insulating Paper
Installation	PCB Mounting
Magnetic Circuit Structure	Combined Type
Voltage Transformation Principle	Capacitive Type
N.W	5.69g
Turns Ratio	1500:1
Inner Hole Size	5mm
Transport Package	Cartons
Specification	ISO9001, ISO14001, ROHS, CE, SGS
Trademark	zeming
Origin	China
HS Code	8504311000
Production Capacity	800.000PCS/Month

Product Description

ZMCT206-1500A Current Transformer

Small size,high accuracy,good consistency,for current and power measurement

Structural parameter: Front view Bottom view The main technical parameters: Applications include detection of branch circuit overload drop or shutdown MATERIAL LIST:

Model	ZMCT206-1500A
input current	0-10A(50Ω)
Output current	4mA at 6A
turns ratio	1500:1
phase angle error	≤20'(input 6A,sampling resistor 50Ω)
linearity	0.2%(5%dot~120%dot of 6A)
Permissible error	-0.2%≤f≤+0.2%(input 6A,sampling resistor 50Ω)
application	current and power measurement
isolation voltage	4000V, 50HZ, 60S
Encapsulation	Epoxy
installation	PCB mounting(Pin length>3mm)
operating temperature	-40ºC~+85ºC
Storage temperature	-40ºC~+125ºC
Working frequency	50/60HZ
Approx. weight	5.69g

CIRCUIT SCHEMATIC: APPLICATIONS:

NO.	Material	Spec, model	UL code	SGS
1	Epoxy coated Nanocrystalline core	1K107, Ø9.5×13×5	--	yes
2	Enameled wire (Winding wire)	2UEW Ø0.08, 1500T	E258243	yes
3	Tape	Flame retardant, Environmental protection, V0 105 degrees, (Plaster)Yellow Glue	E165111	yes
4	Fills and seals material	TXH-9201-10 epoxy resin insulating compound	E196959	yes
5	Outer covering	SF-267 Environmental protection	E238981	yes
6	Cited Needle	Ø0.8×9×3.5	--	yes
7	Solder	YTB101	--	yes
